Single-color PSP
Peregrine
Volume
Price
$700/ unit
About this item
0.7 %/kPa pressure sensitivity for accurate quantitative surface pressure mapping
Low temperature dependency of −0.8 %/°C
40 μs response time suitable for unsteady aerodynamic measurements
Excited at 405 nm or 445 nm; emits at 510–700 nm (peak 580 nm)
Key specifications
Pressure Sensitivity0.7 %/kPa
Temperature Dependency−0.8 %/°C
Response Time40 μs
Excitation405 nm 445 nm
Emission510 – 700 nm, peak @ 580 nm
Specifications are typical values and may vary depending on coating application conditions and measurement setup.
$700
Qty:
Subtotal:
$700.00
Product description
Peregrine is a sprayable, single-color pressure-sensitive paint designed for a wide range of pressure field measurements. Its blue excitation, compatible with 405 nm and 445 nm, supports straightforward integration into many existing wind tunnel facilities and is well suited for first-time PSP implementation. With high pressure sensitivity, low temperature dependence, fast response, and bright visible emission, Peregrine provides a versatile option for a variety of aerodynamic measurement targets.
Technical specifications
| Type | Single-color PSP |
| Pressure Sensitivity | 0.7 %/kPa |
| Temperature Dependency | −0.8 %/°C |
| Response Time | 40 μs |
| Excitation | 405 nm, 445 nm |
| Emission | 510 – 700 nm, peak @ 580 nm |
Specifications are typical values and may vary depending on coating application conditions and measurement setup.
